Brake Disc 14030445

Location:Front wheel Total height:49.6 mm Outer diameter:260.8 mm Center hole diameter:57.9 mm Pitch diameter:100 mm Disc thickness:22.2 mm Minimum disc thickness:20.7 mm Number of holes:5 Solid or ventilated disk:Ventilated disk

Brake Disc 94204836

Location:Front wheel Total height:47 mm Outer diameter:238.8 mm Pitch diameter:87.9 mm Disc thickness:10.2 mm Minimum disc thickness:8.6 mm Number of holes:4 Solid or ventilated disk:Solid disk

Brake Disc 8-94467-837-1

Location:Front wheel Total height:42.9 mm Outer diameter:230.4 mm Center hole diameter:57.2 mm Pitch diameter:100 mm Disc thickness:18 mm Minimum disc thickness:16.6 mm Number of holes:4 Solid or ventilated disk:Ventilated disk Weight:3.5 kg

Brake Disc E1TZ-1102-B

Location:Front wheel Total height:177 mm Outer diameter:319 mm Pitch diameter:165.1 mm Disc thickness:31.8 mm Minimum disc thickness:30 mm Number of holes:8 Solid or ventilated disk:Ventilated disk

Brake Disc 3250577

Location:Front wheel Total height:121.1 mm Outer diameter:261.1 mm Pitch diameter:114.3 mm Disc thickness:22.2 mm Minimum disc thickness:20.6 mm Number of holes:5 Solid or ventilated disk:Ventilated disk

Brake Disc 52010362AA

Location:Rear wheel Total height:71.1 mm Outer diameter:316.5 mm Center hole diameter:90.4 mm Pitch diameter:139.7 mm Disc thickness:22.1 mm Minimum disc thickness:20.6 mm Number of holes:5 Solid or ventilated disk:Ventilated disk

Brake Disc D1FZ 1102 B

Location:Front wheel Total height:96.2 mm Outer diameter:236.2 mm Pitch diameter:108 mm Disc thickness:19 mm Minimum disc thickness:17.4 mm Number of holes:4 Solid or ventilated disk:Ventilated disk

Brake Disc 5469689

Location:Front wheel Total height:122.6 mm Outer diameter:272.3 mm Pitch diameter:114.3 mm Disc thickness:30.1 mm Minimum disc thickness:28.4 mm Number of holes:5 Solid or ventilated disk:Ventilated disk

Brake Disc 893 615 301 A

Location:Front wheel Total height:51.3 mm Outer diameter:255.8 mm Center hole diameter:68.1 mm Pitch diameter:108 mm Disc thickness:21.8 mm Minimum disc thickness:20.1 mm Number of holes:4 Solid or ventilated disk:Ventilated disk

Brake Disc 92218356

Location:Rear wheel Total height:55.4 mm Outer diameter:324.1 mm Center hole diameter:67.6 mm Pitch diameter:120 mm Disc thickness:22.1 mm Minimum disc thickness:20.1 mm Number of holes:5 Solid or ventilated disk:Ventilated disk

Brake Disc 43206-9N00A

Location:Rear wheel Total height:62 mm Outer diameter:307.8 mm Center hole diameter:68.1 mm Pitch diameter:114.3 mm Disc thickness:16 mm Minimum disc thickness:14 mm Number of holes:5 Solid or ventilated disk:Ventilated disk

Brake Disc 8126705

Location:Front wheel Total height:117.6 mm Outer diameter:279 mm Pitch diameter:114.3 mm Disc thickness:25.6 mm Minimum disc thickness:23.9 mm Number of holes:5 Solid or ventilated disk:Ventilated disk

Brake Disc 40206-01P01

Location:Front wheel Total height:35.6 mm Outer diameter:249.7 mm Center hole diameter:81 mm Pitch diameter:103 mm Disc thickness:22.1 mm Minimum disc thickness:20.1 mm Number of holes:4 Solid or ventilated disk:Ventilated disk

Brake Disc C8TZ 1102 B

Location:Front wheel Total height:135.3 mm Outer diameter:319.1 mm Pitch diameter:165.1 mm Disc thickness:25.4 mm Minimum disc thickness:23.9 mm Number of holes:8 Solid or ventilated disk:Ventilated disk

Brake Disc MB 366782

Location:Rear wheel Total height:71.4 mm Outer diameter:281.4 mm Pitch diameter:114.3 mm Disc thickness:10.2 mm Minimum disc thickness:8.4 mm Number of holes:4 Solid or ventilated disk:Solid disk
