CITROEN/FIAT/PEUGEOT Brake Disc 4246.L2

Location:Front wheel Total height:65.5 mm Outer diameter:280 mm Center hole diameter:73 mm Pitch diameter:118 mm Disc thickness:24 mm Minimum disc thickness:21.9 mm Number of holes:5 Solid or ventilated disk:Ventilated disk Weight:7.2 kg

CITROEN/PEUGEOT Brake Disc 4246.N0

Location:Front wheel Total height:28.2 mm Outer diameter:283 mm Center hole diameter:66 mm Pitch diameter:108 mm Disc thickness:26 mm Minimum disc thickness:24.2 mm Number of holes:4 Solid or ventilated disk:Ventilated disk Weight:7 kg

MG (NANJING) Brake Disc 4246.P2

Location:Front wheel Total height:43.7 mm Outer diameter:285 mm Center hole diameter:59 mm Pitch diameter:98 mm Disc thickness:28 mm Minimum disc thickness:26 mm Number of holes:5 Solid or ventilated disk:Ventilated disk Weight:7.9 kg

CITROEN/PEUGEOT/CITROEN (DF-PSA) Brake Disc 4246.R2

Location:Front wheel Total height:27.2 mm Outer diameter:266 mm Center hole diameter:66 mm Pitch diameter:108 mm Disc thickness:13 mm Minimum disc thickness:11 mm Number of holes:4 Solid or ventilated disk:Solid disk Weight:4.1 kg

CITROEN/PEUGEOT Brake Disc 4246.W1

Location:Front wheel Total height:34.2 mm Outer diameter:266 mm Center hole diameter:66 mm Pitch diameter:108 mm Disc thickness:22 mm Minimum disc thickness:20 mm Number of holes:4 Solid or ventilated disk:Ventilated disk Weight:5 kg

CITROEN/PEUGEOT/CITROEN (DF-PSA)/PEUGEOT (DF-PSA) Brake Disc 4246.W2

Location:Front wheel Total height:34.2 mm Outer diameter:283 mm Center hole diameter:66 mm Pitch diameter:108 mm Disc thickness:26 mm Minimum disc thickness:24 mm Number of holes:4 Solid or ventilated disk:Ventilated disk Weight:6.8 kg

CITROEN/PEUGEOT/CITROEN (DF-PSA)/DONGFENG (DFAC)/PEUGEOT (DF-PSA) Brake Disc 4246.X8

Location:Rear wheel Total height:35 mm Outer diameter:247 mm Pitch diameter:108 mm Disc thickness:9 mm Minimum disc thickness:8 mm Number of holes:4 Solid or ventilated disk:Solid disk Weight:3 kg

AUDI/HONGQI/AUDI (FAW) Brake Disc 443 615 301 B

Location:Front wheel Total height:46.5 mm Outer diameter:256 mm Center hole diameter:68 mm Pitch diameter:108 mm Disc thickness:22 mm Minimum disc thickness:20 mm Number of holes:4 Solid or ventilated disk:Ventilated disk Weight:4.9 kg

AUDI Brake Disc 437 615 301 A

Location:Front wheel Total height:46.4 mm Outer diameter:279.8 mm Pitch diameter:112 mm Disc thickness:21.8 mm Minimum disc thickness:20 mm Number of holes:5 Solid or ventilated disk:Ventilated disk Weight:5.9 kg

AUDI Brake Disc 437 615 601

Location:Rear wheel Total height:59.5 mm Outer diameter:245 mm Center hole diameter:68 mm Pitch diameter:112 mm Disc thickness:10 mm Minimum disc thickness:8 mm Number of holes:5 Solid or ventilated disk:Solid disk Weight:3.5 kg

AUDI Brake Disc 441 615 301 A

Location:Front wheel Total height:59.4 mm Outer diameter:276 mm Center hole diameter:68.1 mm Pitch diameter:112 mm Disc thickness:25 mm Minimum disc thickness:23 mm Number of holes:5 Solid or ventilated disk:Ventilated disk Weight:7.1 kg

AUDI Brake Disc 443 615 301

Location:Front wheel Total height:46.5 mm Outer diameter:256 mm Center hole diameter:68 mm Pitch diameter:108 mm Disc thickness:13 mm Minimum disc thickness:11 mm Number of holes:4 Solid or ventilated disk:Solid disk Weight:4.5 kg

AUDI Brake Disc 443 615 601

Location:Rear wheel Total height:59.5 mm Outer diameter:245 mm Center hole diameter:68 mm Pitch diameter:108 mm Disc thickness:10 mm Minimum disc thickness:8 mm Number of holes:4 Solid or ventilated disk:Solid disk Weight:3.5 kg

AUDI Brake Disc 443 615 601 B

Location:Rear wheel Total height:46.5 mm Outer diameter:245 mm Center hole diameter:68 mm Pitch diameter:112 mm Disc thickness:10 mm Minimum disc thickness:8 mm Number of holes:5 Solid or ventilated disk:Solid disk Weight:3.4 kg

AUDI/AUDI (FAW) Brake Disc 443 615 601 E

Location:Rear wheel Total height:65.5 mm Outer diameter:245 mm Pitch diameter:108 mm Disc thickness:10 mm Minimum disc thickness:8 mm Number of holes:4 Solid or ventilated disk:Solid disk Weight:3.63 kg
